Product Detail
1PC Floating Ball Valve
1 piece ball valve and the flange ball valve. The difference is that it’s
closing part is a ball. The ball rotates around the center line of the valve
body to achieve opening and closing. The ball valve is mainly used in the
pipeline to cut off, distribute and change the flow direction of the medium.
- category :Floating Ball Valve
- Email :teji@teji-valve.com
- Phone :+86-577-67354000
- fax :+86-577-67354001
Applied Size:
2“~12”Reduced Bore.
Applied Pressure:
CL150~CL600
Applicable Standard:
●Design Standard: API 6D, ASME B16.34, API 608, BS 5351, MSS SP-72
● Face to Face: API 6D, ASME B16.10, EN 558
● End Connection: Flanged acc. to ASME B16.5
● Inspection and Test: API 6D, API 598
Design Features:
●Blow-out proof stem
● Key lock
● Anti-static device
● Free leakage of body Sealed construction
● Double block&bleed(DBB)
● Emergency sealing
● Various operation types
● Fire safe design to API 607/ API 6FA
● Anti-static to BS 5351
● Cavity pressure self relief
● Optional locking device
